TD-91528 Air Pressure Lock Nut Machine(FOR GAS SPRING)
ID：TD-91528
Introduction
—
Video
TD-91528,OD15mm,Air Pressure End Fitting Nut Machine /GAS SPRING
TD-91528 Gas spring lock end fitting machine-
TD-91528連續操作影片 in factory operate
TD-91528,OD28mm,Air Pressure End Fitting Nut Machine /GAS SPRING
TD-31040,gas spring inner grooving machine,gas spring grooving machine,gas spring end closing machine,Tube rolling machine,gas spring machine,sealing machine for gas spring gas lift ,roll close machine
TD-31040 gas spring cylinder end closing machine,spinning Machine,Sealing machine,CLOSING MACHINE,Spinning Machine,roll close tube equipment
Detailed Information
TD-91528 Air Pressure Lock Nut Machine (Gas spring)-Specification
* Semi-automated, saving manpower
* Fast work efficiency and improve performance
* Precise angle, free to adjust the angle
* Can be set to tighten and hanging loose mode
Control Mode: Touch control
Outside Dia.:15~28mm
Tube Thickness: Not limited
Tube Length:150~800mm
Processing Time:about 5 ~ 8secs.
Machine Power:1.1KW
Machine Length:185cm
Machine Width:70cm
Machine Height:120cm
Net Weight:360kg
Gross Weight:420kg
